110 Degree, Full Overlay, Silentia+ Hinge, Screw-On

Technical Specifications

Adjustment Type: Speed Switch, Angle: 110°, Application Type: Full Overlay, Closing Type: Soft-Close, Door Type: Standard Door, Finish: Nickel, Hinge Cup Depth: 13.5 mm, Hinge Cup Diameter: 35 mm, Hinge Door Drilling Distance: 3 to 6 mm, Hinge Door Thickness: 16 to 26 mm, Mounting Type: Screw-On.

Product Description
Silentia+ delivers smooth, consistent soft-closing performance in any door application or usage condition. Featuring advanced soft-close technology, it ensures reliable and quiet door closure across the entire hinge range.

Engineered with precision, Silentia+ integrates multiple innovative components within a compact design, preserving the sleek aesthetics of the original Silentia hinge series.

Additionally, Silentia+ includes an adjustable deceleration switch that fine-tunes the closing action. This feature enables optimal soft-close performance even on heavier or specialty doors.

Product Advantages

• Integrated soft-close mechanism with twin silicone-oil dampers for smooth and silent door operation
• Adjustable deceleration via a simple, user-friendly switch
• Standard 35 mm diameter hinge cup for easy installation
• Suitable for door thicknesses ranging from 16 mm (5/8") to 26 mm (1")
• 13.5 mm cup depth for secure and stable mounting
• Allows a wide 110° door opening angle
• Flexible drilling distance (K) from 3 to 6 mm for versatile installation
• Fully compatible with all traditional Series 200 and Domi snap-on mounting plates
