110 Degree, Full Overlay, Silentia+ Hinge, Dowel

Specification:

Adjustment Type: Speed Switch, Angle: 110°, Application Type: Full Overlay, Closing Type: Soft-Close, Door Type: Standard Door, Finish: Nickel, Hinge Cup Depth: 13.5 mm, Hinge Cup Diameter: 35 mm, Hinge Door Drilling Distance: 3 to 6 mm, Hinge Door Thickness: 16 to 26 mm, Mounting Type: Dowels.

Product Description
Silentia+ ensures perfect and consistent door closing in any condition, use, or application. Its innovative soft-close technology delivers outstanding performance across the full range of hinges. Designed to fit within required spaces, Silentia+ maintains the sleek aesthetics of the first-generation hinges. It also features an innovative switch that delays the decelerating action, allowing even special doors to achieve the ideal soft-close strength.

Product Advantages
These hinges feature an adjustable integrated soft-close mechanism operated by twin silicone-oil dampers housed in the hinge cup. The deceleration effect is easily adjusted via a simple switch. The hinge cup measures 35 mm in diameter and 13.5 mm in depth, suitable for doors from 16 mm (5/8 inch) to 26 mm (1 inch) thick. It provides a 110° opening angle and supports a door drilling distance (K) from 3 to 6 mm. Silentia+ hinges are compatible with all traditional Series 200 mounting plates as well as all Domi snap-on mounting plates.
